| General |
|---|
| Net Weight |
0.26 kg (0.57 lb) per device |
| Gross Weight |
1.1 kg (2.43 lb) |
| Packing List |
Wireless Bridge × 2,PoE Power Supply × 2,AC Cord × 2,Quick Start Guide ×1,Regulatory Compliance and Safety Information × 1,Binding Tape × 4 |
| Packing Method |
Packing in pairs |
| Storage Humidity |
5% to 95% (no condensation) |
| Working Humidity |
5% to 95% (no condensation) |
| Installation Mode |
Pole Mounting |
| Power Consumption |
2.43 W for typical (1-ch 2MP IPC), Max. 3.6 W |
| Ingress Protection |
IP55 |
| Storage Temperature |
-40 °C to 80 °C (-40 °F to 176 °F) |
| Working Temperature |
-30 °C to 65 °C (-22 °F to 149 °F) |
| Package Dimensions (W × H × D) |
256 mm × 231 mm × 86 mm (10.07" × 9.09" × 3.38") |
| Product Dimensions (W × H × D) |
90.8 mm × 187.87 mm × 57.87 mm (3.58'' × 7.4'' × 2.28'') |
| Approval |
|---|
| EMC |
CE-EMC(EN 55032, EN 55035, EN 61000-3-2, EN IEC 61000-3-2, EN 61000-3-3, EN 50130-4), IC(ICES-003, Issue 7) |
| Radio |
EN 301 893,EN 300 440,EN 62311,EN 301 489-3,EN 301 489-17,EN 301 489-1, EN 55032, EN 55035, , EN 61000-3-2, EN IEC 61000-3-2, EN 61000-3-3, EN 50130-4, EN 50385, EN IEC 62311, EN 62368-1 |
| Safety |
CB (IEC 62368-1),CE-LVD (EN 62368-1) |
| Chemistry |
CE-RoHS (2011/65/EU),WEEE (2012/19/EU),Reach (Regulation (EC) No.1907/2006) |
| PoE Power Supply |
|---|
| PoE Port |
AP: LAN1 802.3af/at PoE IN; CPE: LAN1 passive PoE IN, LAN2 802.3 af PoE OUT |
| PoE Distance |
100 m |
| PoE Power Budget |
10 W |
| Software Function |
|---|
| HPP |
Support one-click activation and remote management via Hik-Partner Pro. Functions supported:
1. Reboot device
2. Restore device
3. Display the topology information
4. Display the connection status between AP and CPEs, including signal intensity, background noise, sending & receiving rate
5. Configure wireless settings, including working mode, SSID, password, channel, channel bandwidth, transmitting power
6. Bridge alignment
7. Spectrum scanning
8. PoE output management |
| Upgrade |
Web,iVMS-4200,HCP,HPP |
| System Log |
Syslog,Control center information |
| Channel Width |
20/40/80 MHz |
| Security Mode |
WPA2-PSK |
| Network Protocol |
NTP (network time synchronization),SADP (auto search for IP address), HTTPS/HTTP (web management),SSH (debugging) |
| Channel Selection |
Auto/manual selection |
| Management Method |
HCP,Web,iVMS-4200,HPP |
| Security Mechanism |
Wireless network name hidden |
| Application Function |
IFM,IPM,DFS,TPC |
| Hardware Parameter |
|---|
| Reset |
Hardware resetting button |
| Power Supply |
48V PoE/12~24V DC;Check the physical interface image below for more details. |
| LED Indicator |
Power indicator,LAN indicator,Signal intensity indicator |
| Network Interface |
2 × 10/100 Mbps RJ45 ports |
| Wireless Parameter |
|---|
| Antenna Gain |
12 dBi |
| Antenna Angle |
(H) Beamwidth [3 dB] 35°, (V) Beamwidth [3 dB] 35° |
| Throughput Rate |
PTP: 90 Mbps/0.5 KM(AC80),90 Mbps/1 KM(AC80),40 Mbps/5 KM(AC80),PTMP(1 to 4): 80 Mbps/1 KM(AC80) |
| Wireless Standard |
IEEE 802.11/a/n/ac |
| Transmitting Power |
22 dBm @11ac MCS0 (Note: Transmitting power may vary with local regulations.) |
| Receiving Sensitivity |
-84 ±2dBm@AC80-MCS0 |
| Working Frequency Band |
5150 MHz ~ 5250 MHz,5250 MHz~ 5350 MHz,5470 MHz~ 5725 MHz,5725 MHz~ 5825 MHz,(Note: Available channel may vary with local regulations.) |
| Max. Transmission Rate of Air Interface |
≤ 867 Mbps |
