| PTZ |
|---|
| Presets |
300 |
| Pan Speed |
Pan speed: configurable from 0.1° to 160°/s, preset speed: 240°/s |
| Tilt Speed |
Tilt speed: configurable from 0.1° to 120°/s, preset speed 200°/s |
| Park Action |
Preset,pattern scan,patrol scan,auto scan,tilt scan,random scan,frame scan,panorama scan |
| Patrol Scan |
8 patrols, up to 32 presets for each patrol |
| Pattern Scan |
4 pattern scans, record time over 10 minutes for each scan |
| 3D Positioning |
Yes |
| Scheduled Task |
Preset,pattern scan,patrol scan,auto scan,tilt scan,random scan,frame scan,panorama scan,dome reboot,aux output,dome adjust |
| Preset Freezing |
Yes |
| Power-off Memory |
Yes |
| Proportional Pan |
Yes |
| PTZ Status Display |
Yes |
| Movement Range (Pan) |
360° |
| Movement Range (Tilt) |
-15° to 90° |
| Lens |
|---|
| FOV |
[Panoramic channel] horizontal field of view: 180°±10°, vertical field of view: 80°±5°
[PTZ channel] horizontal field of view: 60.2° to 2.3°, vertical field of view: 35.2° to 1.3° |
| Focus |
Auto,semi-auto,manual |
| Aperture |
[Panoramic channel] F1.0, [PTZ channel] Max. F1.5 |
| Zoom Speed |
[Panoramic channel] No, [PTZ channel] approx. 5.6 s |
| Focal Length |
[Panoramic channel] 2.8 mm, [PTZ channel] 5.9 to 188.8 mm |
| Audio |
|---|
| Audio Bit Rate |
32 to 192 Kbps (MP2L2),16 to 64Kbps (AAC-LC),8 to 320 Kbps (MP3) |
| Audio Compression |
G.711,G.722.1,G.726,MP2L2,PCM,AAC-LC,MP3 |
| Audio Sampling Rate |
8 kHz,16 kHz,32 kHz,48 kHz |
| Environment Noise Filtering |
yes |
| Event |
|---|
| Linkage |
Upload to FTP/NAS/memory card,notify surveillance center,send email,trigger alarm output,trigger recording,and PTZ actions (such as preset, patrol scan, pattern scan),audible warning,white light flashing |
| Basic Event |
Motion detection,video tampering alarm,alarm input and output,exception (network disconnected, IP address conflict, illegal login, HDD full, HDD error, abnormal restart) |
| Smart Event |
Line crossing detection,intrusion detection,region entrance detection,region exiting detection,audio exception detection |
| Smart Linkage |
panorama linkage, tracking takeover, track in turn |
| Smart Tracking |
Manual tracking,auto-tracking |
| Image |
|---|
| SNR |
＞52dB |
| Defog |
yes |
| Privacy Mask |
24 programmable polygon privacy masks, mask color or mosaic configurable |
| Image Settings |
saturation, brightness, contrast, sharpness |
| Regional Focus |
yes |
| Day/Night Switch |
Day,night,auto,schedule |
| Image Enhancement |
BLC,HLC,3D DNR |
| Regional Exposure |
yes |
| Image Stabilization |
yes |
| Image Parameters Switch |
Yes |
| Wide Dynamic Range (WDR) |
[Panoramic channel] Digital WDR, [PTZ channel] 120 dB |
| Video |
|---|
| H.264 Type |
Baseline Profile,Main Profile,High Profile |
| H.265 Type |
Main Profile |
| Sub-Stream |
[PTZ channel] 50 Hz: 25 fps (704 × 576, 640 × 480, 352 × 288), 60 Hz: 30 fps (704 × 480, 640 × 480, 352 × 240),[Panoramic channel] 50 Hz: 25 fps (1200 × 536, 960 × 432), 60 Hz: 30 fps (1200 × 536, 960 × 432) |
| Main Stream |
[PTZ channel] 50 Hz: 25 fps (2560 × 1440, 1920 × 1080, 1280 × 960, 1280 × 720), 60 Hz: 30 fps (2560 × 1440, 1920 × 1080, 1280 × 960, 1280 × 720),[Panoramic channel] 50 Hz: 25 fps (3632 × 1632, 3680 × 1656), 60 Hz: 30 fps (3632 × 1632, 3680 × 1656) |
| Third Stream |
[PTZ channel] 50 Hz: 25 fps (1920 × 1080, 1280 × 960, 1280 × 720, 704 × 576, 640 × 480, 352 × 288), 60 Hz: 30 fps (1920 × 1080, 1280 × 960, 1280 × 720, 704 × 480, 640 × 480, 352 × 240),[Panoramic channel] No |
| Video Bit Rate |
32 Kbps to 16384 Mbps |
| Video Compression |
Main stream: H.265+/H.265/H.264+/H.264,
Sub-stream: H.265/H.264/MJPEG,
Third stream: H.265/H.264/MJPEG |
| Region of Interest (ROI) |
fixed region |
| Scalable Video Coding (SVC) |
yes |
| Camera |
|---|
| HLC |
yes |
| Zoom |
32 × optical,16 × digital |
| 3D DNR |
yes |
| Day & Night |
IR cut filter |
| Image Sensor |
[Panoramic channel] 1/2.5" Progressive Scan CMOS, [PTZ channel] 1/2.8" Progressive Scan CMOS |
| Slow Shutter |
yes |
| Shutter Speed |
1 s to 1/30,000 s |
| Max. Resolution |
[Panoramic channel] 3632 × 1632, [PTZ channel] 2560 × 1440 |
| Min. Illumination |
[PTZ channel] Color: 0.005 Lux @ (F1.5, AGC ON), B/W: 0.001 Lux @ (F1.5, AGC ON), 0 lux with IR,[Panoramic channel] Color: 0.0005 Lux @ (F1.0, AGC ON), 0 Lux with Light |
| General |
|---|
| Power |
24 VAC, Max. 60 W, Hi-PoE |
| Demist |
Yes |
| Material |
ADC12,Plastic,PC+10%GF |
| Dimension |
Ø222.3 mm × 387.2 mm (Ø8.75" × 15.2") |
| General Function |
mirror,watermark,password protection,IP address filter |
| Operating Condition |
-30 °C to 65 °C (-22 °F to 149 °F). Humidity 90% or less (non-condensing) |
| Network |
|---|
| API |
ISUP,SDK,ISAPI,Open Network Video Interface (Profile S, Profile G, Profile T) |
| Client |
iVMS-4200,HikCentral Pro,Hik-Connect |
| Security |
Password protection,HTTPS encryption,802.1X authentication (EAP-TLS, EAP-LEAP, EAP-MD5),host authentication (MAC address),IP address filter |
| Protocols |
TCP/IP,ICMP,HTTP,HTTPS,FTP,DHCP,DNS,DDNS,RTP,RTSP,RTCP,PPPoE,NTP,UPnP,SMTP,SNMP,IGMP,802.1X,QoS,IPv4/IPv6,UDP,Bonjour,WebSocket,WebSockets,SRTP |
| User/Host |
32 |
| Web Browser |
IE 11+, Chrome 57+, Firefox 52+, Safari 12+, Edge79.0.309.65+ |
| Network Storage |
NAS (NFS, SMB/CIFS),auto network replenishment (ANR) |
| Simultaneous Live View |
20 |
| Approval |
|---|
| Protection |
IP66 (IEC 60529-2013) |
| Interface |
|---|
| Alarm |
2 input(s), 1 output(s) |
| Audio |
1 input (line in), max. input amplitude: 2-2.4 vpp, input impedance: 1 KΩ ± 10%,
1 output (line out), line level, output impedance: 600 Ω |
| Reset |
Yes |
| On-board Storage |
Built-in memory card slot, support Micro SD/Micro SDHC/Micro SDXC, up to 256 GB |
| Ethernet Interface |
1 RJ45 10/100M self-adaptive Ethernet port |
| Illuminator |
|---|
| White Light Distance |
Panoramic channel: 30 m |
| Supplement Light Range |
IR distance: up to 200 m |
| Deep Learning Function |
|---|
| Face Capture |
Support detecting up to 5 faces at the same time. Support detecting, tracking, capturing, grading, selecting of face in motion, and output the best face picture of the face |
| Regional People Counting |
Yes |
