| Lens |
|---|
| Focus |
Auto,Semi-auto,Manual |
| Aperture |
2.8 to 12 mm: F1.47 to F2.5
8 to 32 mm: F1.6 |
| Iris Type |
P-iris |
| Focal Length & FOV |
2.8 to 12 mm, horizontal FOV 106° to 41.8°, vertical FOV 55.4° to 23.6°, diagonal FOV 130° to 48.1°
8 to 32 mm, horizontal FOV 42.5° to 15.2°, vertical FOV 23.4° to 8.7°, diagonal FOV 49.7° to 17.3° |
| Audio |
|---|
| Audio Type |
Mono sound |
| Audio Bit Rate |
64 Kbps (G.711ulaw/G.711alaw)/16 Kbps (G.722.1)/16 Kbps (G.726)/32 to 192 Kbps (MP2L2)/8 to 320 Kbps (MP3)/16 to 64 Kbps (AAC-LC) |
| Audio Compression |
G.711/G.722.1/G.726/MP2L2/PCM/MP3/AAC-LC |
| Audio Sampling Rate |
8 kHz/16 kHz/32 kHz/48 kHz |
| Environment Noise Filtering |
Yes |
| Event |
|---|
| Linkage |
Upload to FTP/NAS/memory card,notify surveillance center,send email,trigger alarm output,trigger recording,trigger capture,audible warning |
| Basic Event |
Motion detection (support alarm triggering by specified target types (human and vehicle)),video tampering alarm,video quality diagnosis,exception (network disconnected, IP address conflict, illegal login, abnormal restart, HDD full, HDD error),vibration detection |
| Smart Event |
scene change detection,audio exception detection,defocus detection |
| Image |
|---|
| SNR |
≥ 52 dB |
| Privacy Mask |
8 programmable polygon privacy masks |
| Image Settings |
Rotate mode,saturation,brightness,contrast,sharpness,white balance,AGC,adjustable by client software or web browser |
| Picture Overlay |
LOGO picture can be overlaid on video with 128 × 128 24 bit bmp format. |
| Day/Night Switch |
Day,Night,Auto,Schedule,Alarm Trigger |
| Image Enhancement |
BLC,HLC,3D DNR,Distortion Correction,Defog |
| Image Stabilization |
EIS |
| Image Parameters Switch |
Yes |
| Wide Dynamic Range (WDR) |
140 dB |
| Video |
|---|
| e-PTZ |
Support Patrol and Auto Tracking settings |
| H.264 Type |
Baseline Profile,Main Profile,High Profile |
| H.265 Type |
Main Profile |
| Sub-Stream |
50 Hz: 25 fps (1280 × 720, 704 × 576, 640 × 480)
60 Hz: 30 fps (1280 × 720, 704 × 480, 640 × 480) |
| Main Stream |
Monitoring mode:
50 Hz: up to 50 fps (2688 × 1520, 2560 × 1440, 1280 × 720), up to 100 fps (1920 × 1080)
60 Hz: up to 60 fps (2688 × 1520, 2560 × 1440, 1280 × 720), up to 120 fps (1920 × 1080)
*High frame rate is supported under monitoring mode only.
smart mode:
50 Hz: 25 fps (2688 × 1520, 2560 × 1440, 1920 × 1080, 1280 × 720)
60 Hz: 30 fps (2688 × 1520, 2560 × 1440, 1920 × 1080, 1280 × 720) |
| Fifth Stream |
50 Hz: 25 fps (1280 × 720, 704 × 576, 640 × 480)
60 Hz: 30 fps (1280 × 720, 704 × 480, 640 × 480) |
| Third Stream |
50 Hz: 25 fps (1920 × 1080, 1280 × 720, 704 × 576, 640 × 480)
60 Hz: 30 fps (1920 × 1080, 1280 × 720, 704 × 480, 640 × 480) |
| Fourth Stream |
50 Hz: 25 fps (1280 × 720, 704 × 576, 640 × 480)
60 Hz: 30 fps (1280 × 720, 704 × 480, 640 × 480) |
| Video Bit Rate |
32 Kbps to 8 Mbps |
| Target Cropping |
Yes |
| Bit Rate Control |
CBR,VBR |
| Video Compression |
Main stream: H.265+/H.265/H.264+/H.264,
Sub-stream: H.265/H.264/MJPEG,
Third stream: H.265/H.264,
Fourth stream: H.265/H.264/MJPEG,
Fifth stream: H.265/H.264/MJPEG |
| Region of Interest (ROI) |
4 fixed regions for each stream |
| Scalable Video Coding (SVC) |
H.264 and H.265 encoding |
| Camera |
|---|
| Day & Night |
IR cut filter,
Blue glass module (less ghost phenomenon) |
| Image Sensor |
1/1.8" Progressive Scan CMOS |
| Shutter Time |
1 s to 1/100,000 s |
| Max. Resolution |
2688 × 1520 |
| Min. Illumination |
Color: 0.0005 Lux @ (F1.2, AGC ON),B/W: 0.0001 Lux @ (F1.2, AGC ON),B/W: 0 Lux with IR,0 Lux with light |
| General |
|---|
| Power |
three-core terminal block,
12 VDC ± 20%, 1.8 A, max. 21.5 W,
24 VAC ± 20%, 1.47 A, max. 21 W,
PoE: IEEE 802.3at, Type 2, Class 4, 42.5 V to 57 V, 0.55 A to 0.41 A, max. 23.1 W |
| Demist |
Yes |
| Heater |
Yes |
| Language |
33 languages: English, Russian, Estonian, Bulgarian, Hungarian, Greek, German, Italian, Czech, Slovak, French, Polish, Dutch, Portuguese, Spanish, Romanian, Danish, Swedish, Norwegian, Finnish, Croatian, Slovenian, Serbian, Turkish, Korean, Traditional Chinese, Thai, Vietnamese, Japanese, Latvian, Lithuanian, Portuguese (Brazil), Ukrainian |
| Material |
Aluminum alloy body |
| Dimension |
With -Y: Ø140 mm × 377.4 mm (Ø5.5" × 14.9"), Without -Y: Ø144.1 mm × 374.7 mm (Ø5.7" × 14.8") |
| General Function |
Heartbeat,anti-banding,one-key reset,mirror,password protection,flash log |
| Device Management |
Supports adding alarm box (DS-FM2466) in the LAN to expand 6 additional input and 6 output alarm interfaces |
| Package Dimension |
425 mm × 190 mm × 180 mm (16.7" × 7.5" × 7.1") |
| Storage Conditions |
-40 °C to 65 °C (-40 °F to 149 °F). Humidity 95% or less (non-condensing) |
| With Package Weight |
Without -Y: Approx. 3364 g (7.42 lb.), -Y: Approx. 3406 g (7.5 lb.) |
| Integrated Connector Panel |
-Y: No |
| Startup and Operating Conditions |
-40 °C to 65 °C (-40 °F to 149 °F). Humidity 95% or less (non-condensing) |
| Network |
|---|
| API |
ISAPI,SDK,ISUP,OTAP,ONVIF (Profile S, Profile G, Profile T, Profile M) |
| Client |
iVMS-4200,Hik-Connect,Hik-Central |
| Security |
Password protection, complicated password, HTTPS encryption, 802.1X authentication (EAP-TLS, EAP-LEAP, EAP-MD5), watermark, IP address filter, basic and digest authentication for HTTP/HTTPS, WSSE and digest authentication for Open Network Video Interface, RTP/RTSP OVER HTTPS, Control Timeout Settings, Security Audit Log, TLS 1.2, TLS 1.3, TPM 2.0 (FIPS 140-2 level 2), AES128/256 |
| Protocols |
TCP/IP, ICMP, HTTP, HTTPS, FTP, SFTP, DHCP, DNS, DDNS, SRTP, RTP, RTSP, RTCP, PPPoE, NTP, UPnP, SMTP, SNMP, IGMP, 802.1X, QoS, IPv4, IPv6, UDP, Bonjour, SSL/TLS, ARP, WebSocket, WebSockets |
| User/Host |
Up to 32 users
3 user levels: administrator, operator, and user |
| Web Browser |
Plug-in required live view: IE 10, IE 11,
Plug-in free live view: Chrome 57.0+, Firefox 52.0+, Edge 89+, Safari 11+,
Local service: Chrome 57.0+, Firefox 52.0+, Edge 89+ |
| Network Storage |
NAS (NFS, SMB/CIFS),Auto Network Replenishment (ANR),
Together with high-end Hikvision memory card, memory card encryption and health detection are supported. |
| Simultaneous Live View |
Up to 20 channels |
| Approval |
|---|
| EMC |
CE-EMC: EN 55032:2015+A1:2020, EN 50130-4:2011+A1:2014, EN IEC 61000-3-2:2019+A1:2021, EN 61000-3-3:2013+A1:2019+A2:2021,
RCM: AS/NZS CISPR 32: 2015,
IC: ICES-003: Issue 7,
KC: KN32: 2015, KN35: 2015 |
| Other |
PVC FREE |
| Safety |
CB: IEC 62368-1: 2014+A11,
CE-LVD: EN 62368-1: 2014/A11: 2017,
BIS: IS 13252 (Part 1): 2010/IEC 60950-1: 2005,
LOA: IEC/EN 60950-1 |
| Protection |
IP67: IEC 60529-2013,IK10: IEC 62262:2002 |
| Environment |
CE-RoHS: 2011/65/EU,
WEEE: 2012/19/EU,
Reach: Regulation (EC) No 1907/2006 |
| Automotive and Railway |
EN50121-4 |
| Anti-Corrosion Protection |
-Y: NEMA 4X (NEMA 250-2018) |
| Interface |
|---|
| Alarm |
2 inputs, 2 outputs (max. 24 VDC/24 VAC, 1 A) |
| Audio |
1 input (line in), 3.5 mm connector, three-contact, max. input amplitude: 3.3 Vpp, input impedance: 4.7 KΩ, interface type: non-equilibrium,
1 output (line out), 3.5 mm connector, three-contact, max. output amplitude: 3.3 Vpp, output impedance: 100 Ω, interface type: non-equilibrium, mono sound |
| RS-485 |
-Y: 1 RS-485 (Half duplex, HIKVISION, Pelco-P, Pelco-D, self-adaptive) |
| Reset Key |
Yes |
| Power Output |
-Y: 12 VDC, max. 100 mA |
| Video Output |
1 Vp-p Composite Output (75 Ω/CVBS) (Only for debugging) |
| Built-in Speaker |
1 built-in speaker,Max. power consumption: 1.5 W |
| On-Board Storage |
Built-in memory card slot, support microSD/microSDHC/microSDXC card, up to 1 TB |
| Ethernet Interface |
1 RJ45 10 M/100 M/1000 M self-adaptive Ethernet port |
| Built-in Microphone |
2 built-in microphones |
| Illuminator |
|---|
| IR Wavelength |
850 nm |
| Supplement Light Type |
IR,White Light |
| Smart Supplement Light |
Yes |
| Supplement Light Range |
2.8 to 12 mm: Monitoring: 60 m; 8 to 32 mm: Monitoring: 100 m |
| Pixel Density |
|---|
| DORI |
Wide:
2.8 to 12 mm: D (Detect): 64.7 m, O (Observe): 25.7 m, R (Recognize): 12.9 m, I (Identify): 6.5 m
8 to 32 mm: D (Detect) : 150.3 m, O (Observe) : 59.7 m, R (Recognize) : 30.1 m, I (Identify) : 15 m
Tele:
2.8 to 12 mm: D (Detect): 151.7 m, O (Observe): 60.2 m, R (Recognize): 30.3 m, I (Identify): 15.2 m
8 to 32 mm: D (Detect) : 400 m, O (Observe) : 158.7 m, R (Recognize) : 80 m, I (Identify) : 40 m
The DORI values are calculated using pixel densities for different use cases as recommended by the EN 62676-4 standard. |
| Deep Learning Function |
|---|
| Metadata |
Intrusion detection,line crossing detection,region entrance detection,region exiting detection |
| Perimeter Protection |
Line crossing, intrusion, region entrance, region exiting
Support alarm triggering by specified target types (human and vehicle)
Support combined event alarm triggering
Dedicated large scale AI model for perimeter protection, reduce false alarms by 90% compared to conventional AI cameras
VCA range: up to 80m(nighttime)/100m(daytime)
*Result based on standard setup and test environment |
