| Lens |
|---|
| Focus |
Auto,Semi-auto,Manual |
| Aperture |
2.8 to 12 mm: F1.2 to 2.5
8 to 32 mm: F1.7 to F1.73 |
| Iris Type |
P-iris |
| Focal Length & FOV |
2.8 to 12 mm, horizontal FOV: 114.5° to 41.8°, vertical FOV: 59.3° to 23.6°, diagonal FOV: 141.1° to 48°
8 to 32 mm, horizontal FOV: 42.5° to 15.1°, vertical FOV: 23.3° to 8.64°, diagonal FOV: 49.6° to 17.3° |
| Audio |
|---|
| Audio Type |
Mono sound |
| Audio Bit Rate |
64 Kbps (G.711ulaw/G.711alaw)/16 Kbps (G.722.1)/16 Kbps (G.726)/32 to 192 Kbps (MP2L2)/8 to 320 Kbps (MP3)/16 to 64 Kbps (AAC-LC) |
| Audio Compression |
G.711/G.722.1/G.726/MP2L2/PCM/MP3/AAC-LC |
| Audio Sampling Rate |
8 kHz/16 kHz/32 kHz/44.1 kHz/48 kHz |
| Environment Noise Filtering |
Yes |
| Event |
|---|
| Linkage |
Upload to FTP/NAS/memory card,notify surveillance center,send email,trigger alarm output,trigger recording,trigger capture,audible warning |
| Basic Event |
Motion detection (support alarm triggering by specified target types (human and vehicle)),video tampering alarm,exception (network disconnected, IP address conflict, illegal login, abnormal restart, HDD full, HDD error),video quality diagnosis,vibration detection |
| Smart Event |
scene change detection,audio exception detection,defocus detection |
| Image |
|---|
| SNR |
≥ 52 dB |
| Privacy Mask |
8 programmable polygon privacy masks |
| Image Settings |
Rotate mode,saturation,brightness,contrast,sharpness,white balance,AGC,adjustable by client software or web browser |
| Picture Overlay |
LOGO picture can be overlaid on video with 128 × 128 24 bit bmp format. |
| Day/Night Switch |
Day,Night,Auto,Schedule,Alarm Trigger |
| Image Enhancement |
BLC,HLC,3D DNR,Distortion Correction,Defog |
| Image Stabilization |
EIS |
| Image Parameters Switch |
Yes |
| Wide Dynamic Range (WDR) |
140 dB |
| Video |
|---|
| e-PTZ |
Support Patrol and Auto Tracking settings |
| H.264 Type |
Baseline Profile,Main Profile,High Profile |
| H.265 Type |
Main Profile |
| Sub-Stream |
50 Hz: 25 fps (704 × 576, 640 × 480)
60 Hz: 30 fps (704 × 480, 640 × 480) |
| Main Stream |
50 Hz:
25 fps (2688 × 1520, 2560 × 1440, 1920 × 1080, 1280 × 720)
50 fps (2560 × 1440, 1920 × 1080, 1280 × 720)
60 Hz:
30 fps (2688 × 1520, 2560 × 1440, 1920 × 1080, 1280 × 720)
60 fps (2560 × 1440, 1920 × 1080, 1280 × 720) |
| Fifth Stream |
50 Hz: 25 fps (704 × 576, 640 × 480)
60 Hz: 30 fps (704 × 480, 640 × 480) |
| Third Stream |
50 Hz: 25 fps (1920 × 1080, 1280 × 720, 704 × 576, 640 × 480)
60 Hz: 30 fps (1920 × 1080, 1280 × 720, 704 × 480, 640 × 480) |
| Fourth Stream |
50 Hz: 25 fps (704 × 576, 640 × 480)
60 Hz: 30 fps (704 × 480, 640 × 480) |
| Video Bit Rate |
32 Kbps to 8 Mbps |
| Target Cropping |
Yes |
| Bit Rate Control |
CBR,VBR |
| Video Compression |
Main stream: H.265+/H.265/H.264+/H.264,
Sub-stream: H.265/H.264/MJPEG,
Third stream: H.265/H.264,
Fourth stream: H.265/H.264/MJPEG,
Fifth stream: H.265/H.264/MJPEG |
| Region of Interest (ROI) |
4 fixed regions for each stream |
| Scalable Video Coding (SVC) |
H.264 and H.265 encoding |
| Camera |
|---|
| Day & Night |
IR cut filter
Blue glass module to reduce ghost phenomenon |
| Image Sensor |
1/1.8" Progressive Scan CMOS |
| Shutter Time |
1 s to 1/100,000 s |
| Max. Resolution |
2688 × 1520 |
| Angle Adjustment |
Pan: 0° to 355°, tilt: 0° to 75°, rotate: 0° to 355° |
| Min. Illumination |
Color: 0.0005 Lux @ (F1.2, AGC ON); B/W: 0.0001 Lux @ (F1.2, AGC ON), 0 Lux with IR |
| General |
|---|
| Power |
12 VDC ± 20%, 1.02 A, max. 12.4 W, two-core terminal block
24 VAC ± 20%, 0.49 A, max. 11.8 W, two-core terminal block
PoE: IEEE 802.3at, Type 2, Class 4, 42.5 V to 57 V, 0.22 A to 0.29 A, max. 12.5 W |
| Language |
33 languages: English, Russian, Estonian, Bulgarian, Hungarian, Greek, German, Italian, Czech, Slovak, French, Polish, Dutch, Portuguese, Spanish, Romanian, Danish, Swedish, Norwegian, Finnish, Croatian, Slovenian, Serbian, Turkish, Korean, Traditional Chinese, Thai, Vietnamese, Japanese, Latvian, Lithuanian, Portuguese (Brazil), Ukrainian |
| Material |
Aluminum alloy body |
| Dimension |
Ø140.5 mm × 122.6 mm (Ø5.5" × 4.8") |
| General Function |
Heartbeat, mirror, password protection, one-key reset |
| Device Management |
Supports adding alarm box (DS-FM2466) in the LAN to expand 6 additional input and 6 output alarm interfaces |
| Package Dimension |
244 mm × 174 mm × 173 mm (9.6" × 6.9" × 6.8") |
| Storage Conditions |
-30 °C to 60 °C (-22 °F to 140 °F). Humidity 95% or less (non-condensing) |
| With Package Weight |
Approx. 1415 g (3.11 lb.) |
| Startup and Operating Conditions |
-30 °C to 60 °C (-22 °F to 140 °F). Humidity 95% or less (non-condensing) |
| Network |
|---|
| API |
Open Network Video Interface (Profile S, Profile G, Profile T, Profile M),ISAPI,SDK,ISUP |
| Client |
iVMS-4200,Hik-Connect,Hik-Central |
| Security |
Password protection, complicated password, HTTPS encryption, 802.1X authentication (EAP-TLS, EAP-LEAP, EAP-MD5), watermark, IP address filter, basic and digest authentication for HTTP/HTTPS, WSSE and digest authentication for Open Network Video Interface, RTP/RTSP OVER HTTPS, Control Timeout Settings, Security Audit Log, TLS 1.2, TLS 1.3, TPM 2.0 (FIPS 140-2 level 2), AES128/256 |
| Protocols |
TCP/IP, ICMP, HTTP, HTTPS, FTP, SFTP, SRTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, PPPoE, NTP,UPnP, SMTP, SNMP, IGMP, 802.1X, QoS, IPv4, IPv6, UDP, Bonjour, SSL/TLS, WebSocket, WebSockets |
| User/Host |
Up to 32 users
3 user levels: administrator, operator, and user |
| Web Browser |
Plug-in required live view: IE 10, IE 11,
Plug-in free live view: Chrome 57.0+, Firefox 52.0+, Edge 89+, Safari 11+,
Local service: Chrome 57.0+, Firefox 52.0+, Edge 89+ |
| Network Storage |
NAS (NFS, SMB/CIFS),Auto Network Replenishment (ANR),
Together with high-end Hikvision memory card, memory card encryption and health detection are supported. |
| Simultaneous Live View |
Up to 20 channels |
| Approval |
|---|
| CC |
Common Criteria, Assurance Level: EAL2 + ALC_FLR.2 |
| EMC |
FCC: 47 CFR Part 15, Subpart B,
CE-EMC: EN 55032: 2015, EN 61000-3-2:2019, EN 61000-3-3: 2013+A1:2019, EN 50130-4: 2011 +A1: 2014,
RCM: AS/NZS CISPR 32: 2015,
IC: ICES-003: Issue 7,
KC: KN32: 2015, KN35: 2015 |
| Other |
PVC FREE |
| Safety |
UL: UL 62368-1,
CB: IEC 62368-1: 2014+A11,
CE-LVD: EN 62368-1: 2014/A11: 2017,
BIS: IS 13252 (Part 1): 2010/IEC 60950-1: 2005,
LOA: IEC/EN 60950-1 |
| Protection |
IK10: IEC 62262:2002 |
| Environment |
CE-RoHS: 2011/65/EU,
WEEE: 2012/19/EU,
Reach: Regulation (EC) No 1907/2006 |
| Interface |
|---|
| Alarm |
1 input, 1 output (max. 24 VDC, 1 A) |
| Audio |
1 input (line in), 1 output (line out), 3.5 mm connector |
| RS-485 |
1 RS-485 (Half duplex, HIKVISION, Pelco-P, Pelco-D, self-adaptive) |
| Reset Key |
Yes |
| Power Output |
12 VDC, max. 100 mA |
| Video Output |
1 Vp-p Composite Output (75 Ω/CVBS) (Only for debugging) |
| On-Board Storage |
Built-in memory card slot, support microSD/microSDHC/microSDXC card, up to 1 TB |
| Ethernet Interface |
1 RJ45 10 M/100 M/1000 M self-adaptive Ethernet port |
| Built-in Microphone |
Yes,1 built-in microphone |
| Illuminator |
|---|
| IR Wavelength |
850 nm |
| Supplement Light Type |
IR |
| Smart Supplement Light |
Yes |
| Supplement Light Range |
2.8 to 12 mm: 30 m
8 to 32 mm: 50 m |
| Pixel Density |
|---|
| DORI |
Wide:
2.8 to 12 mm: D (Detect): 60 m, O (Observe): 23.8 m, R (Recognize): 12 m, I (Identify): 6 m
8 to 32 mm: D (Detect): 150.3 m, O (Observe): 59.7 m, R (Recognize): 30.1 m, I (Identify): 15 m
Tele:
2.8 to 12 mm: D (Detect): 149 m, O (Observe): 59.1 m, R (Recognize): 29.8 m, I (Identify): 14.9 m
8 to 32 mm: D (Detect): 400 m, O (Observe): 158.7 m, R (Recognize): 80 m, I (Identify): 40 m |
| AI Open Platform |
|---|
| Model Specification |
Up to 4 models,
Model type: detection model, classification model, mixed model (detection model and classification model) |
| Deep Learning Function |
|---|
| Heat Map |
A graphic description of visits (by calculating amount of people or amount of dwell time) in a configured area.,
Two report types are available, space heat map and time heat map line chart. |
| Metadata |
Intrusion detection,line crossing detection,region entrance detection,region exiting detection,face capture,multi-target-type detection |
| Face Capture |
Detects up to 120 faces simultaneously, captures up to 40 face pictures per frame simultaneously and uploads up to 10 face pictures per second,
Supports swing left and right from -60° to 60°, tilt up and down from -30° to 30°,
Uploads face with background and closed-up face pictures,
Supports best shot and quick shot for capture mode,
Supports dynamic mosaic mask,
Gets 7 face features |
| Face Comparison |
Up to 10 face libraries. 30,000 faces for each library. 150,000 faces in total,
Supports face library encryption |
| People Counting |
Supports Multi-Dimension People Counting,
Supports counting, displaying and exporting the people flow data of entering, exiting and passing by (The data is stored in the flash.),
Supports real-time uploading and uploading by statistic cycle,
Supports generating daily, weekly, monthly or annually reports,
Supports dynamic deduplication based on face picture comparison, and can filter out the target with the same custom face pictures, same attributes, or filter out repeated invalid targets within the set time interval,
Supports face feature deduplication,
Supports people flow data replenishment |
| Queue Management |
Supports up to 8 detection regions, and independent arming schedule and linkage method
Supports 2 detection modes: regional people queuing-up, waiting time detection
Generates reports to compare the efficiency of different queuing-ups and display the changing status of one queue
Supports raw data export for further analysis
Supports real-time data uploading and scheduled data uploading
Regional people queuing-up: supports 4 alarm trigger conditions, including greater than threshold, less than threshold, equal to threshold, not equal to threshold
Waiting time detection: supports 1 alarm trigger condition, including greater than threshold |
| Hard Hat Detection |
Detects up to 30 human targets simultaneously
Supports up to 4 shield regions |
| Perimeter Protection |
Line crossing, intrusion, region entrance, region exiting
Support alarm triggering by specified target types (human and vehicle)
Support combined event alarm triggering |
| On/Off Duty Detection |
Supports up to 8 detection regions, and independent arming schedule and linkage method
Supports 2 detection modes: absence detection, on/off duty detection
Supports parameter settings: person on duty, absence duration |
| Regional People Counting |
Supports up to 8 detection regions, and independent arming schedule and linkage method
Supports 3 detection modes: people density detection, number of people exception detection, waiting time exception detection
Supports parameter settings: alarm times per exception, alarm interval, first alarm delay
Supports searching real-time number of people
People density detection: supports scheduled uploading, number of people change uploading, congestion level uploading
Number of people exception detection: supports 6 alarm trigger conditions, including greater than threshold A, less than threshold A, equal to threshold A, not equal to threshold A, greater than threshold A and less than threshold B, less than threshold A or greater than threshold B (threshold A should be less than threshold B)
Waiting time exception detection: supports 3 alarm trigger conditions, including greater than threshold A, less than threshold A, greater than threshold A and less than threshold B (threshold A should be less than threshold B) |
| Multi-target-type Detection |
Supports simultaneous detection and capture of human body, face, and vehicle,
Gets 7 face features,
Gets 13 human body features,
Gets 2 vehicle features,
Supports counting the number of line crossing targets by type, including human body, non-motor vehicle, motor vehicle,
Supports dynamic mosaic mask |
