| DORI |
|---|
| DORI |
Wide: D(Detect): 67.2 m, O(Observe): 26.6 m, R(Recognize): 13.44 m, I(Identify): 6.72 m
Tele: D(Detect): 204 m, O(Observe): 80.9 m, R(Recognize): 40.8 m, I(Identify): 20.4 m
The DORI values are calculated using pixel densities for different use cases as recommended by the EN 62676-4 standard. |
| Lens |
|---|
| FOV |
Horizontal FoV: 99° to 30.4°, Vertical FoV: 52.9° to 17.2°, Diagonal FoV: 117.7° to 34.9° |
| Focus |
Auto |
| Aperture |
F1.6 |
| Iris Type |
Fixed |
| Focal Length |
2.8 to 12 mm |
| Audio |
|---|
| Audio Type |
Mono sound |
| Audio Bit Rate |
64 Kbps（G.711ulaw/G.711alaw）/16 Kbps（G.722.1）/16 Kbps（G.726）/32~192 Kbps（MP2L2）/16~64 Kbps（AAC-LC）/8~320 Kbps（MP3） |
| SNR (A-Weighted) |
85 dB |
| Audio Compression |
G.711a/G.711u/G.722.1/G.726/MP2L2/PCM/AAC-LC/MP3 |
| Audio Sampling Rate |
8 kHz/16 kHz/32 kHz/44.1 kHz/48 kHz |
| Environment Noise Filtering |
Support |
| Event |
|---|
| Linkage |
Upload to FTP/NAS/SD card, notify surveillance center, send email, trigger alarm output, trigger recording, audible warning, white light flashing |
| Basic Event |
Motion detection, video tampering alarm, alarm input, exception, video quality diagnosis, defocus detection, audio exception detection, scene change detection |
| Smart Event |
Line crossing detection, intrusion detection, region entrance detection, region exiting detection |
| Image |
|---|
| White Balance |
Auto,
Manual |
| Image Settings |
Saturation, brightness, contrast, sharpness, white balance, adjustable by client software or web browser |
| Day/Night Switch |
Day, Night, Auto, Schedule, Alarm Trigger |
| Image Enhancement |
BLC, HLC, 3D DNR, Defog, EIS |
| Image Parameters Switch |
Support |
| Video |
|---|
| H.264 Type |
BaseLine Profile/Main Profile/High Profile |
| H.265 Type |
Main Profile |
| Sub-Stream |
50 Hz: 25 fps (704 × 576，640 × 480)
60 Hz: 30 fps (704 × 480，640 × 480) |
| Main Stream |
50 Hz：25 fps (2560 × 1440, 1920 × 1080, 1280 × 720)
60 Hz：30 fps (2560 × 1440, 1920 × 1080, 1280 × 720) |
| Fifth Stream |
50 Hz：25 fps（704 × 576，640 × 480）
60 Hz：30 fps（704 × 480，640 × 480） |
| Third Stream |
50 Hz：25 fps（1920 × 1080，1280 × 720，704 × 576，640 × 480）
60 Hz：30 fps（1920 × 1080，1280 × 720，704 × 480，640 × 480） |
| Fourth Stream |
50 Hz：25 fps（704 × 576，640 × 480）
60 Hz：30 fps（704 × 480，640 × 480） |
| Picture Overlay |
LOGO picture can be overlaid on video with 128 × 128 24 bit bmp format. |
| Target Cropping |
Support |
| Bit Rate Control |
CBR, VBR |
| Simultaneous Live View |
Up to 20 Channels |
| Region of Interest (ROI) |
4 fixed regions for main stream, sub-stream, third stream, fourth stream, and fifth stream |
| Scalable Video Coding (SVC) |
Support |
| Camera |
|---|
| Day & Night |
ICR |
| Image Sensor |
1/3" Progressive Scan CMOS |
| Shutter Time |
1 s to 1/100,000 s |
| Max. Resolution |
2560 × 1440 |
| Angle Adjustment |
Vertical: 0° to 80° |
| Adjustment Method |
Manual Adjustment |
| Min. Illumination |
Color: 0.005 Lux @(F1.6, AGC ON) Black&White: 0 Lux with IR |
| General |
|---|
| Color |
Gray |
| Power |
PoE: 42.5 V to 57 V, 0.447 A to 0.6 A, max. 25.5W,12 VDC, 2.125 A, max. 25.5 W |
| Language |
English, Bulgarian, Czech, Danish, German, Greek, Spanish (European), Estonian, Persian, Finnish, French (European), Hebrew, Croatian, Hungarian, Indonesian, Italian, Japanese, Kazakh, Korean, Lithuanian, Latvian, Dutch, Norwegian, Polish, Portuguese (European), Portuguese (Brazilian), Romanian, Russian, Slovak, Slovenian, Serbian, Swedish, Thai, Turkish, Ukrainian, Uzbek, Vietnamese, Traditional Chinese (Taiwan) |
| Material |
Metal |
| Dimension |
338 mm × 244.9 mm × 190.1 mm (13.31” × 9.64” × 7.48”) |
| Package Dimension |
420 mm × 280 mm × 316 mm (16.54” × 11.02” × 12.44”) |
| Operating Humidity |
Humidity 95% or less (non-condensing) |
| With Package Weight |
5.07 kg (11.18 lb.) |
| Operating Temperature |
-30 °C to 60 °C (-22 °F to 140 °F) |
| Bracket Adjustment Angle |
-53° to 165° |
| Network |
|---|
| Client |
iVMS-4200, HikConnect, HikCentral Professional |
| Browser |
Plug-in required live view: IE10, IE11.
Local service: Chrome 57.0+, Firefox 52.0+.
Plug-in free live view: Chrome 57.0+, Firefox 52.0+, Safari 12+ |
| Network Storage |
Support MicroSD/MicroSDHC/MicroSDXC cards (up to 512 GB) with automatic network replenishment and local storage, NAS (NFS, SMB/CIFS), Together with high-end Hikvision memory card, memory card encryption and health detection are supported |
| User Management |
Up to 32 users. 3 user levels: administrator, operator, and user |
| Network Protocol |
TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, PPPoE, NTP, UPnP, SMTP, SNMP, IGMP, 802.1X, QoS, IPv6, UDP, Bonjour, WebSocket, WebSockets |
| Network Security |
Password protection, complicated password, HTTPS encryption, 802.1X authentication (EAP-TLS, EAP-LEAP, EAP-MD5), watermark, IP address filter, basic and digest authentication for HTTP/HTTPS, WSSE and digest authentication for Open Network Video Interface, RTP/RTSP OVER HTTPS, Control Timeout Settings, Security Audit Log, TLS 1.2 |
| Interface Protocol (API) |
Open Network Video Interface, ISAPI, ISUP5.0 |
| Speaker |
|---|
| Impedance |
8 Ω |
| Rated Power |
7 W |
| Speaker Unit |
Dome Tweeter |
| Frequency Response |
500 Hz to 6 kHz |
| Sensitivity(1 m, 1 W) |
107 dB |
| Maximum Sound Pressure Level |
115 dBSPL |
| Total Harmonic Distortion (THD) |
5 % |
| Approval |
|---|
| EMC |
Class B |
| Safety |
CB: IEC 62368-1: 2014+A11,
CE-LVD: EN 62368-1: 2014/A11: 2017, |
| Protection |
IP67 |
| Environment |
CE-RoHS: 2011/65/EU,
WEEE: 2012/19/EU,
Reach: Regulation (EC) No 1907/2006 |
| Function |
|---|
| Two-Way Audio |
Support |
| Audio Algorithm |
AEC, NS, AGC, DRC |
| Interface |
|---|
| Alarm |
1 input, 1 output |
| Reset |
1 |
| RS-485 |
1 |
| MicroSD |
Built-in MicroSD/MicroSDHC/MicroSDXC slot, up to 512 GB |
| Local Storage |
8 GB EMMC |
| Power Interface |
1 power input, phoenix terminal |
| Network Interface |
1 RJ45 10 M/100 M/1000 M self-adaptive Ethernet port |
| Microphone |
|---|
| Type |
electret |
| Amount |
2 |
| Sensitivity |
-32 dBV/Pa |
| Sampling Rate |
48 kHz |
| Quantization Bits |
16 bit |
| Frequency Response |
100 Hz to 20 kHz |
| Illuminator |
|---|
| IR Wavelength |
850 nm |
| Supplement Light Type |
Hybrid (IR and White Light) |
| Smart Supplement Light |
Yes |
| Supplement Light Range |
White Light: Up to 20 m,IR: Up to 50 m |
| Deep Learning Function |
|---|
| Metadata |
Intrusion detection,line crossing detection,region entrance detection,region exiting detection |
| Perimeter Protection |
Line crossing, intrusion, region entrance, region exiting
Support alarm triggering by specified target types (human and vehicle)
Dedicated large scale AI model for perimeter protection, reduce false alarms by 90% compared to conventional AI cameras |
