| RAID |
|---|
| RAID Type |
RAID0, RAID1, RAID5, RAID6, RAID10 |
| General |
|---|
| Chassis |
2U chassis |
| Consumption |
≤ 50 W (without HDD) |
| Power Supply |
100 to 240 VAC, 50 to 60 Hz, redundant power supply |
| Working Humidity |
10% to 90% |
| Working Temperature |
-10 °C to 55 °C (14 °F to 131 °F) |
| Dimension (W × D × H) |
445 × 540 × 93 mm ( 17.5"× 21.3" × 3.7") |
| Network |
|---|
| Network Protocol |
TCP/IP, DHCP, IPv4, IPv6, DNS, DDNS, NTP, RTSP, SADP, SMTP, SNMP, NFS, iSCSI, ISUP, UPnP™, HTTP, HTTPS, ONVIF(Version 2.2), OTAP |
| Network Interface |
2, RJ-45 10/100/1000 Mbps self-adaptive Ethernet interface |
| Camera Access Protocol |
ONVIF(Version 2.5), RTSP |
| Decoding |
|---|
| Decoding Format |
H.265+/H.265/H.264+/H.264 |
| Audio Compression |
G.711ulaw/G.711alaw/G.722/G.726/AAC/MP2L2/PCM |
| Decoding Capability |
2-ch@32 MP (30 fps); 3-ch@24 MP (30 fps); 4-ch@16MP (30 fps); 6-ch@12MP (30 fps);10-ch@8 MP (30 fps); 13-ch@6 MP (30 fps);16-ch@5 MP (30 fps);32-ch@2 MP(30 fps) |
| Recording Resolution |
32 MP/24 MP/12 MP/8 MP/6 MP/5 MP/4 MP/3 MP/1080p/UXGA/720p/VGA /4CIF/DCIF/ 2CIF/CIF/QCIF
*: The NVR supports up to 8-ch 32/24/16 MP IP video inputs, all channels for less than 16 MP. |
| Synchronous playback |
16-ch |
| Certification |
|---|
| CE |
EN 55032:2015, EN 61000-3-2, EN 61000-3-3, EN 50130-4 |
| FCC |
Part 15 Subpart B, ANSI C63.4-2014 |
| Obtained Certification |
CE, FCC |
| Cyber Security |
|---|
| Others |
Digest authentication: Support
User access log : Support
Centralized certificate management : Support
Brute force delay protection : Support |
| EN 303645 |
Support |
| Secure Boot |
Support |
| Signed Firmware |
Support |
| HTTPS Encryption |
Support |
| Password Protection |
Support |
| IP & MAC Address Filtering |
Support |
| Secure Component Verification SVC |
Support |
| Live View & Playback Stream Encryption |
Support |
| IEEE802.1X(EAP-TLS) Network Access Control |
Support |
| Video and Audio |
|---|
| CVBS Output |
1-ch, BNC (1.0 Vp-p, 75 Ω), resolution: PAL: 704 × 576, NTSC: 704 × 480 |
| Audio Output |
2-ch, RCA (Linear, 1 KΩ) |
| VGA 1 Output |
1920 × 1080/60Hz |
| VGA 2 Output |
1920 × 1080/60Hz |
| HDMI 1 Output |
8K(7680×4320)/30Hz, 4K（3840×2160）/60Hz,4K（3840×2160）/30Hz，2K（2560×1440）/60Hz，1080P（1920×1080）/60Hz |
| HDMI 2 Output |
4K (3840 × 2160)/60Hz, 4K (3840 × 2160)/30Hz, 2K (2560 × 1440)/60Hz, 1920 × 1080/60Hz *: When HDMI 1 output resolution is 8K, the maximum HDMI 2 output resolution is 1080p. |
| Two-Way Audio |
1-ch, RCA (2.0 Vp-p, 1 KΩ, using the audio input) |
| IP Video Input |
32-ch |
| Video Output Mode |
HDMI 1 and VGA 1 provide simultaneous video output, and work as the main output;
HDMI 2 and VGA 2 provide simultaneous video output, and work as the auxiliary output |
| Incoming Bandwidth |
320 Mbps |
| Outgoing Bandwidth |
400 Mbps |
| Auxiliary Interface |
|---|
| SATA |
8 SATA interfaces |
| eSATA |
1 eSATA interface |
| DC 12V |
12 VDC, 1 A power output |
| Capacity |
Up to 20 TB capacity for each disk |
| Ctrl 12V |
Controllable 12 VDC, 1 A power output for external alarm device; The power will be turned on when the alarm output is triggered.
*: The Ctrl 12V power is controlled by alarm output 9. |
| Alarm In/Out |
16/9 |
| USB Interface |
Front panel: 2 × USB 2.0; Rear panel: 2 × USB 3.0 |
| Serial Interface |
1 RS-485 (full-duplex), 1 RS-232 |
