| AcuSeek |
|---|
| Performance |
If the cameras support Hikvision AcuSense Technology and have enabled AcuSearch function, the NVR supports AcuSeek in all channels, capable of modeling 50,000 targets/day. |
| Search Language |
English |
| General |
|---|
| Consumption |
≤ 10 W (without HDD) |
| GUI Language |
English,Russian,Bulgarian,Hungarian,Greek,German,Italian,Czech,Slovakia,French,Polish,Dutch,Portuguese,Spanish,Romanian,Turkish,Japanese,Danish,Swedish,Norwegian,Finnish,Korean,TraChinese,Thai,Estonia,Vietnamese,Croatian,Slovenian,Serbian,Latvian,Lithuanian,Uzbek,Kazak,Arabic,Hebrew,Ukrainian,Indonesian |
| Power Supply |
12 VDC, 1.5 A |
| Working Humidity |
10 to 90 % |
| Working Temperature |
-10 °C to 55 °C (14 °F to 131 °F) |
| Dimension (W × D × H) |
319 mm × 239 mm × 48 mm (12.6 × 9.4 × 1.9 inch) |
| Network |
|---|
| Network Protocol |
TCP/IP, DHCP, IPv4, IPv6, DNS, DDNS, NTP, RTSP, SADP, SMTP, SNMP, NFS, iSCSI, ISUP, UPnP™, HTTP, HTTPS |
| Network Interface |
1 RJ-45 10/100/1000 Mbps self-adaptive Ethernet interface |
| Remote Connection |
128 |
| Decoding |
|---|
| Stream Type |
Video, Video & Audio |
| Decoding Format |
H.265/H.265+/H.264/H.264+ |
| Audio Compression |
G.711ulaw/G.711alaw/G.722/G.726/AAC/MP2L2 |
| Decoding Capability |
AI on: 2-channel 12 MP@30 fps, 3-channel 8 MP@30 fps, 4-channel 6 MP@30 fps, 4-channel 4 MP@30 fps, 4-channel 3 MP@30fps, 4-channel 2 MP@30fps
AI off: 4-channel 12 MP@30 fps, 4-channel 8 MP@30 fps, 4-channel 6 MP@30 fps, 4-channel 4 MP@30 fps, 4-channel 3 MP@30fps, 4-channel 2 MP@30fps |
| Recording Resolution |
12 MP/8 MP/6 MP/5 MP/4 MP/3 MP/1080p/UXGA/720p/VGA /4CIF/DCIF /2CIF/CIF/QCIF |
| Synchronous playback |
4-ch |
| AcuSearch |
|---|
| By Camera |
All channels
*: The camera should enable AcuSearch function |
| Certification |
|---|
| CE |
EN 55032: 2015, EN 61000-3-2, EN 61000-3-3, EN 50130-4, EN 55035: 2017 |
| Obtained Certification |
CE,CB,REACH,WEEE,UKCA,RCM,IC |
| Video and Audio |
|---|
| VGA Output |
1080P（1920×1080）/60Hz，UXGA（1600×1200）/60Hz，SXGA（1280×1024）/60Hz，720P（1280×720）/60Hz |
| Audio Input |
Two-Way Audio 1-ch, RCA (2.0 Vp-p, 1 KΩ, using the audio input) |
| HDMI Output |
4K（3840×2160）/30Hz，2K（2560×1440）/60Hz，1080P（1920×1080）/60Hz，UXGA（1600×1200）/60Hz，SXGA（1280×1024）/60Hz，720P（1280×720）/60Hz |
| Audio Output |
1-ch, RCA (Linear, 1 KΩ) |
| IP Video Input |
4-ch |
| IP Speaker Input |
4-ch |
| Video Output Mode |
HDMI/VGA independent output |
| Incoming Bandwidth |
40 Mbps |
| Outgoing Bandwidth |
80 Mbps |
| Target Recognition |
|---|
| Face Picture Library |
Up to 16 face picture libraries, with up to 50,000 face pictures in total (each picture ≤ 1 MB, total capacity ≤ 800 MB) |
| Face Picture Comparison |
4-ch |
| Facial Detection and Analytics |
Face picture comparison, human face capture, face picture search |
| Facial Detection and Analytics Performance |
Up to 4 MP: 2-ch;
5 MP to 8 MP: 1-ch |
| Auxiliary Interface |
|---|
| SATA |
1 SATA interface |
| Capacity |
Up to 16 TB capacity for each HDD |
| Alarm In/Out |
4/1 |
| USB Interface |
Front panel: 1 × USB 2.0; Rear panel: 1 × USB 2.0 |
| Motion Detection 2.0 |
|---|
| By NVR |
All channels, up to 4 MP (when enhanced SVC mode is enabled, up to 8 MP) video analysis for human and vehicle recognition to reduce false alarm |
| By Camera |
All channels |
| Perimeter Protection |
|---|
| By NVR |
Video analysis (HD network camera, H.264/H.265) for human and vehicle recognition to reduce false alarm.
Up to 4 MP: 2-ch;
5 MP to 8 MP: 1-ch |
| By Camera |
All channels |
| Intelligent Analytics |
|---|
| AI by NVR |
Facial recognition, perimeter protection, motion detection 2.0, AcuSearch, AcuSeek |
| AI by NVR and Camera |
Facial recognition, perimeter protection, motion detection2.0, ANPR, VCA |
