| DORI |
|---|
| DORI |
Wide: D: 60.0m, O: 23.8 m, R: 12.0 m, I: 6.0 m
Tele: D: 149 m, O: 59.1 m, R: 29.8 m, I: 14.9 m |
| Lens |
|---|
| Aperture |
F1.2 |
| Iris Type |
Fixed |
| Lens Type |
Varifocal lens, motorized lens, 2.8 to 12 mm |
| Lens Mount |
Integrated |
| Depth of Field |
1 m to ∞ |
| Focal Length & FOV |
2.8 to 12 mm, horizontal FOV 114.6° to 41.8°, vertical FOV 59.3° to 23.6°, diagonal FOV 141.3° to 48.1° |
| Audio |
|---|
| Audio Bit Rate |
64 Kbps (G.711ulaw/G.711alaw)/16 Kbps (G.722.1)/16 Kbps (G.726)/16 Kbps to 64 Kbps (AAC-LC)/32 to 192 Kbps (MP2L2)/8 to 320 Kbps (MP3) |
| Audio Compression |
G.711ulaw/G.711alaw/G.722.1/G.726/MP2L2/PCM/MP3/AAC-LC |
| Audio Sampling Rate |
8 kHz/16 kHz/32 kHz/44.1 kHz/48 kHz |
| Environment Noise Filtering |
Yes |
| Event |
|---|
| Linkage |
Upload to FTP/NAS/memory card,notify surveillance center,trigger recording,trigger capture,send email,audible warning,trigger alarm output |
| Basic Event |
Motion detection (support alarm triggering by specified target types (human and vehicle)),video tampering alarm,exception |
| Smart Event |
Scene change detection |
| Image |
|---|
| SNR |
≥ 52 dB |
| Privacy Mask |
4 programmable polygon privacy masks |
| Image Settings |
Rotate mode,saturation,brightness,contrast,sharpness,gain,white balance,adjustable by client software or web browser |
| Day/Night Switch |
Day,Night,Auto,Schedule |
| Image Enhancement |
BLC,HLC,3D DNR |
| Image Parameters Switch |
Yes |
| Wide Dynamic Range (WDR) |
130 dB |
| Video |
|---|
| H.264 Type |
Baseline Profile,Main Profile,High Profile |
| H.265 Type |
Main Profile |
| Sub-Stream |
50 Hz: 25 fps (1280 × 720, 640 × 480, 640 × 360)
60 Hz: 30 fps (1280 × 720, 640 × 480, 640 × 360) |
| Main Stream |
50 Hz: 25 fps (2688 × 1520, 1920 × 1080, 1280 × 720)
60 Hz: 30 fps (2688 × 1520, 1920 × 1080, 1280 × 720) |
| Third Stream |
50 Hz: 10 fps (1920 × 1080, 1280 × 720, 640 × 480, 640 × 360)
60 Hz: 10 fps (1920 × 1080, 1280 × 720, 640 × 480, 640 × 360)
*Third stream is supported under certain settings. |
| Video Bit Rate |
32 Kbps to 8 Mbps |
| Bit Rate Control |
CBR,VBR |
| Video Compression |
Main stream: H.265/H.264/H.264+/H.265+,
Sub-stream: H.265/H.264/MJPEG,
Third stream: H.265/H.264,
*Third stream is supported under certain settings. |
| Region of Interest (ROI) |
1 fixed region for main stream and sub-stream |
| Scalable Video Coding (SVC) |
H.264 and H.265 encoding |
| Camera |
|---|
| Day & Night |
IR cut filter |
| Image Sensor |
1/1.8" Progressive Scan CMOS |
| Shutter Time |
1/3 s to 1/100,000 s |
| Max. Resolution |
2688 × 1520 |
| Angle Adjustment |
Pan: 0° to 355°,tilt: 0° to 90°,rotate: 0° to 360° |
| Min. Illumination |
Color: 0.0008 Lux @ (F1.2, AGC ON),0 Lux with light |
| General |
|---|
| Power |
12 VDC ± 25%, 1.21 A, max. 14.5 W,Ø5.5 mm coaxial power plug,reverse polarity protection,
PoE: IEEE 802.3at, Class 4, max. 18 W |
| Language |
33 languages: English, Russian, Estonian, Bulgarian, Hungarian, Greek, German, Italian, Czech, Slovak, French, Polish, Dutch, Portuguese, Spanish, Romanian, Danish, Swedish, Norwegian, Finnish, Croatian, Slovenian, Serbian, Turkish, Korean, Traditional Chinese, Thai, Vietnamese, Japanese, Latvian, Lithuanian, Portuguese (Brazil), Ukrainian |
| Material |
Front cover: Metal, body: Metal, bracket: Metal |
| Dimension |
298 mm × 97.9 mm × 95.7 mm (11.8" × 3.9" × 3.8") |
| General Function |
Heartbeat,mirror,password reset via email,pixel counter,anti-banding |
| Package Dimension |
386 mm × 190 mm × 180 mm (15.2" × 7.5" × 7.1") |
| Storage Conditions |
-30 °C to 60 °C (-22 °F to 140 °F). Humidity 95% or less (non-condensing) |
| With Package Weight |
Approx. 1639 g (3.6 lb.) |
| Startup and Operating Conditions |
-30 °C to 60 °C (-22 °F to 140 °F). Humidity 95% or less (non-condensing) |
| Network |
|---|
| API |
Open Network Video Interface (Profile S, Profile G, Profile T),ISAPI,SDK,ISUP |
| Client |
iVMS-4200,Hik-Connect,Hik-Central |
| Security |
Password protection, complicated password, HTTPS encryption, 802.1X authentication (EAP-TLS, EAP-LEAP, EAP-MD5), watermark, IP address filter, basic and digest authentication for HTTP/HTTPS, WSSE and digest authentication for Open Network Video Interface, RTP/RTSP over HTTPS, control timeout settings, security audit log, TLS 1.1/1.2/1.3, host authentication (MAC address) |
| Protocols |
TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, NTP, UPnP, SMTP, IGMP, 802.1X, QoS, IPv4, IPv6, UDP, Bonjour, SSL/TLS, PPPoE, SNMP, WebSocket, WebSockets, SRTP, SFTP |
| User/Host |
Up to 32 users
3 user levels: administrator, operator, and user |
| Web Browser |
Plug-in required live view: IE 10, IE 11,
Plug-in free live view: Chrome 57.0+, Firefox 52.0+, Edge 89+,
Local service: Chrome 57.0+, Firefox 52.0+, Edge 89+ |
| Network Storage |
NAS (NFS, SMB/CIFS),Auto Network Replenishment (ANR) |
| Simultaneous Live View |
Up to 6 channels |
| Approval |
|---|
| EMC |
CE-EMC: EN 55032: 2015, EN 61000-3-2:2019, EN 61000-3-3: 2013+A1:2019, EN 50130-4: 2011 +A1: 2014 |
| Safety |
UL: UL 62368-1,
CB: IEC 62368-1: 2014+A11,
CE-LVD: EN 62368-1: 2014/A11: 2017 |
| Protection |
IP67: IEC 60529-2013,IK10: IEC 62262:2002 |
| Environment |
CE-RoHS: 2011/65/EU |
| Interface |
|---|
| Alarm |
1 input, 1 output (max. 24 VDC/24 VAC, 1 A) |
| Audio |
1 input (line in), two-core terminal block, max. input amplitude: 3.3 Vpp, input impedance: 4.7 KΩ, interface type: non-equilibrium,
1 output (line out), two-core terminal block, max. output amplitude: 3.3 Vpp, output impedance: 100 Ω, interface type: non-equilibrium |
| Reset Key |
Yes |
| On-Board Storage |
Built-in memory card slot, support microSD/microSDHC/microSDXC card, up to 512 GB |
| Ethernet Interface |
1 RJ45 10 M/100 M self-adaptive Ethernet port |
| Illuminator |
|---|
| IR Wavelength |
850 nm |
| Supplement Light Type |
IR,White Light |
| Smart Supplement Light |
Yes |
| Supplement Light Range |
Up to 60 m |
| Deep Learning Function |
|---|
| Face Capture |
Yes |
| Perimeter Protection |
Line crossing, intrusion, region entrance, region exiting
Support alarm triggering by specified target types (human and vehicle) |
