| Lens |
|---|
| Aperture |
F1.6 |
| Iris Type |
Fixed |
| Lens Type |
Fixed focal lens, 2.8 and 4 mm optional |
| Lens Mount |
M12 |
| Depth of Field |
2 mm: 0.6 m to ∞
2.8 mm: 1.4 m to ∞
4 mm: 1.6 m to ∞ |
| Focal Length & FOV |
2 mm, horizontal FOV 128°, vertical FOV 75°, diagonal FOV 147°
2.8 mm, horizontal FOV 104.3°, vertical FOV 55.9°, diagonal FOV 123.8°
4 mm, horizontal FOV 83.7°, vertical FOV 43.0°, diagonal FOV 100.3° |
| Audio |
|---|
| Audio Bit Rate |
64 Kbps (G.711ulaw/G.711alaw)/16 Kbps (G.722.1)/16 Kbps (G.726)/32-192 Kbps (MP2L2)/8-320 Kbps (MP3)/16-64 Kbps (AAC-LC) |
| Audio Compression |
G.711ulaw/G.711alaw/G.722.1/G.726/MP2L2/PCM/MP3/AAC-LC |
| Audio Sampling Rate |
8 kHz/16 kHz/32 kHz/44.1 kHz/48 kHz |
| Environment Noise Filtering |
Yes |
| Event |
|---|
| Linkage |
Upload to FTP/NAS/memory card, notify surveillance center, trigger recording, trigger capture, send email |
| Basic Event |
Motion detection (human and vehicle targets classification), video tampering alarm, exception |
| Smart Event |
Line crossing detection, intrusion detection (support alarm triggering by specified target types (human and vehicle))
Face detection |
| Image |
|---|
| SNR |
≥ 52 dB |
| Image Settings |
Rotate, mirror, privacy mask, saturation, brightness, contrast, sharpness, gain, white balance adjustable by client software or web browser |
| Day/Night Switch |
Day, Night, Auto, Schedule |
| Image Enhancement |
BLC, HLC, 3D DNR |
| Image Parameters Switch |
Yes |
| Wide Dynamic Range (WDR) |
120 dB |
| Video |
|---|
| H.264 Type |
Baseline Profile/Main Profile/High Profile |
| H.265 Type |
Main Profile |
| Sub-Stream |
50 Hz: 25 fps (1280 × 720, 640 × 480, 640 × 360)
60 Hz: 30 fps (1280 × 720, 640 × 480, 640 × 360) |
| Main Stream |
50 Hz: 25 fps (2688 × 1520, 1920 × 1080, 1280 × 720)
60 Hz: 30 fps (2688 × 1520, 1920 × 1080, 1280 × 720) |
| Third Stream |
50 Hz: 10 fps (1920 × 1080, 1280 × 720, 640 × 480, 640 × 360)
60 Hz: 10 fps (1920 × 1080, 1280 × 720, 640 × 480, 640 × 360)
*Third stream is supported under certain settings. |
| Video Bit Rate |
32 Kbps to 8 Mbps |
| Bit Rate Control |
CBR/VBR |
| Video Compression |
Main stream: H.265/H.264/H.265+/H.264+
Sub-stream: H.265/H.264/MJPEG
Third stream: H.265/H.264
*Third stream is supported under certain settings. |
| Region of Interest (ROI) |
1 fixed region for main stream and sub-stream |
| Scalable Video Coding (SVC) |
H.264 and H.265 encoding |
| Wi-Fi |
|---|
| Modulation |
-W:
802.11b: CCK, QPSK, BPSK
802.11g/n: OFDM |
| Transfer Rate |
-W:
802.11b: 11 Mbps
802.11g: 54 Mbps
802.11n: up to 300 Mbps |
| Wi-Fi Protocol |
-W:
802.11b: CCK, QPSK, BPSK
802.11g/n: OFDM |
| Wireless Range |
-W: Up to 80 m (The performance varies based on actual environment) |
| Encryption Mode |
-W: 64/128-bit WEP, WPA-EAP/WPA2-EAP, WPA-PSK/WPA2-PSK |
| Frequency Range |
-W: 2.4 GHz to 2.4835 GHz |
| Channel Bandwidth |
-W: 20/40 MHz |
| Camera |
|---|
| Day & Night |
IR cut filter |
| Image Sensor |
1/3" Progressive Scan CMOS |
| Shutter Time |
1/3 s to 1/100,000 s |
| Max. Resolution |
2688 × 1520 |
| Angle Adjustment |
Pan: -30° to 30°, tilt: 0° to 75°, rotate: 0° to 360° |
| Min. Illumination |
Color: 0.005 Lux @ (F1.6, AGC ON), B/W: 0 Lux with IR |
| General |
|---|
| Power |
-IS:
12 VDC ± 25%, 0.45 A, max. 5.5 W, Ø5.5 mm coaxial power plug, reverse polarity protection
PoE: 802.3af, Class 3, 36 V to 57 V, 0.18 A to 0.11 A, max. 6.5 W
-IWS:
12 VDC ± 25%, 0.5 A, max. 6 W, Ø5.5 mm coaxial power plug, reverse polarity protection
PoE: 802.3af, Class 3, 36 V to 57 V, 0.19 A to 0.12 A, max. 7 W |
| Weight |
Approx. 380 g (0.8 lb.) |
| Language |
33 languages: English, Russian, Estonian, Bulgarian, Hungarian, Greek, German, Italian, Czech, Slovak, French, Polish, Dutch, Portuguese, Spanish, Romanian, Danish, Swedish, Norwegian, Finnish, Croatian, Slovenian, Serbian, Turkish, Korean, Traditional Chinese, Thai, Vietnamese, Japanese, Latvian, Lithuanian, Portuguese (Brazil), Ukrainian |
| Dimension |
Ø110 mm × 57.4 mm (Ø 4.3" × 2.3") |
| General Function |
Anti-flicker, heartbeat, password reset via email, pixel counter |
| Package Dimension |
134 mm × 134 mm × 108 mm (5.3" × 5.3" × 4.3") |
| Storage Conditions |
-30 °C to 60 °C (-22 °F to 140 °F). Humidity 95% or less (non-condensing) |
| With Package Weight |
Approx. 615 g (1.4 lb.) |
| Startup and Operating Conditions |
-30 °C to 60 °C (-22 °F to 140 °F). Humidity 95% or less (non-condensing) |
| Network |
|---|
| API |
Open Network Video Interface (Profile S, Profile G), ISAPI, SDK |
| Client |
iVMS-4200, Hik-Connect, Hik-Central
*Wi-Fi connection with Hik-Connect directly is not possible. |
| Security |
Password protection, complicated password, HTTPS encryption, IP address filter, Security Audit Log, basic and digest authentication for HTTP/HTTPS, TLS 1.1/1.2, WSSE and digest authentication for Open Network Video Interface |
| Protocols |
TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, NTP, UPnP, SMTP, IGMP, 802.1X (except for -W model), QoS, IPv6, UDP, Bonjour, SSL/TLS, PPPoE, WebSocket, WebSockets |
| User/Host |
Up to 32 users. 3 user levels: administrator, operator and user |
| Web Browser |
Plug-in required live view: IE 10, IE 11
Plug-in free live view : Chrome 57.0+, Firefox 52.0+
Local service: Chrome 57.0+, Firefox 52.0+ |
| Network Storage |
NAS (NFS, SMB/CIFS), auto network replenishment (ANR) |
| Simultaneous Live View |
Up to 6 channels |
| Approval |
|---|
| RF |
-W:
FCC ID (FCC Part 15.247(BT or 2.4G));
CE-RED (EN 301489-1 V2.1.1(BT or 2.4G); EN 301489-17 V3.1.1(BT or 2.4G); EN 300328 V2.1.1(BT or 2.4G); EN 62311:2008(BT or 2.4G)) |
| EMC |
FCC (47 CFR Part 15, Subpart B)
CE-EMC (EN 55032: 2015, EN 61000-3-2: 2019, EN 61000-3-3: 2013+A1: 2019, EN 50130-4: 2011+A1: 2014)
RCM (AS/NZS CISPR 32: 2015)
IC (ICES-003: Issue 7)
KC (KN32: 2015, KN35: 2015) |
| Safety |
UL (UL 62368-1)
CB (IEC 62368-1: 2014+A11)
CE-LVD (EN 62368-1: 2014/A11: 2017) |
| Protection |
IP67 (IEC 60529-2013)
IK8 (IEC 62262:2002) |
| Environment |
CE-RoHS (2011/65/EU)
WEEE (2012/19/EU)
Reach (Regulation (EC) No 1907/2006) |
| Interface |
|---|
| Alarm |
-IS/IWS:
1 input, 1 output (max. 12 VDC, 20 mA) |
| Audio |
-IS/IWS:
1 input (line in), two-core terminal block, max. input amplitude: 3.3 Vpp, input impedance: 4.7 KΩ, interface type: non-equilibrium
1 output (line out), two-core terminal block, max. output amplitude: 3.3 Vpp, output impedance: 100 Ω, interface type: non-equilibrium |
| Reset Key |
Yes |
| On-Board Storage |
Built-in memory card slot, support microSD card, up to 512 GB |
| Ethernet Interface |
1 RJ45 10 M/100 M self-adaptive Ethernet port |
| Built-in Microphone |
Yes |
| Illuminator |
|---|
| IR Wavelength |
850 nm |
| Supplement Light Type |
IR |
| Smart Supplement Light |
Yes |
| Supplement Light Range |
Up to 30 m |
| Pixel Density |
|---|
| DORI |
2 mm, D: 45 m, O: 18 m, R: 9 m, I: 4 m
2.8 mm: D: 64 m, O: 25 m, R: 13 m, I: 6 m
4 mm: D: 85 m, O: 34 m, R: 17 m, I: 9 m |
