| Lens |
|---|
| Aperture |
F1.0 |
| Iris Type |
Fixed |
| Lens Type |
Fixed focal lens, 2.8 and 4 mm optional |
| Lens Mount |
M16 |
| Depth of Field |
2.8 mm: 2.5 m to ∞
4 mm: 2.8 m to ∞ |
| Focal Length & FOV |
2.8 mm, horizontal FOV 104°, vertical FOV 54.4°, diagonal FOV 126.7°
4 mm, horizontal FOV 89.3°, vertical FOV 48.2°, diagonal FOV 106.5° |
| Audio |
|---|
| Audio Type |
Mono sound |
| Audio Bit Rate |
64 Kbps (G.711)/16 Kbps (G.722.1)/16 Kbps (G.726)/32 to 160 Kbps (MP2L2)/16 to 64 Kbps (AAC-LC) |
| Audio Compression |
G.711/G.722.1/G.726/MP2L2/PCM/MP3/AAC-LC |
| Audio Sampling Rate |
8 kHz/16 kHz |
| Environment Noise Filtering |
Yes |
| Event |
|---|
| Linkage |
Upload to FTP,notify surveillance center,send email,trigger recording,trigger capture |
| Basic Event |
Motion detection (support alarm triggering by specified target types (human and vehicle)),video tampering alarm,exception |
| Image |
|---|
| SNR |
≥ 52 dB |
| Privacy Mask |
4 programmable polygon privacy masks |
| Image Settings |
Rotate mode,saturation,brightness,contrast,sharpness,gain,white balance,adjustable by client software or web browser |
| Day/Night Switch |
Day,Night,Auto,Schedule |
| Image Enhancement |
BLC,HLC,3D DNR |
| Wide Dynamic Range (WDR) |
120 dB |
| Video |
|---|
| H.264 Type |
Baseline Profile,Main Profile,High Profile |
| H.265 Type |
Main Profile |
| Sub-Stream |
50 Hz: 25 fps (768 × 432, 640 × 360)
60 Hz: 24 fps (768 × 432, 640 × 360) |
| Main Stream |
50 Hz:
25 fps (2560 × 1440, 1920 × 1080, 1280 × 720)
60 Hz:
24 fps (2560 × 1440, 1920 × 1080, 1280 × 720) |
| Video Bit Rate |
32 Kbps to 16 Mbps |
| Bit Rate Control |
CBR,VBR |
| Video Compression |
Main stream: H.265+/H.265/H.264+/H.264,
Sub-stream: H.265/H.264/MJPEG |
| Region of Interest (ROI) |
1 fixed region for main stream |
| Scalable Video Coding (SVC) |
H.264 and H.265 encoding |
| Camera |
|---|
| Day & Night |
IR cut filter |
| Image Sensor |
1/1.8" Progressive Scan CMOS |
| Shutter Time |
1 s to 1/100,000 s |
| Max. Resolution |
2560 × 1440 |
| Angle Adjustment |
Pan: 0° to 360°,tilt: 0° to 90°,rotate: 0° to 360° |
| Min. Illumination |
Color: 0.0001 Lux @ (F1.0, AGC ON) |
| General |
|---|
| Power |
12 VDC ± 25%, 0.58 A, max. 7 W,Ø5.5 mm coaxial power plug,reverse polarity protection,
PoE: IEEE 802.3af, Class 3, max. 9 W |
| Weight |
Approx. 310 g (0.7 lb.) |
| Language |
English, Russian, Ukrainian, Arabic, Spanish, French, Portuguese, Turkish, Polish, German |
| Material |
Cover: PLASTIC, main body: METAL |
| Dimension |
69.1 mm × 66.9 mm × 172.9 mm (2.7" × 2.6" × 6.8") |
| Flashing Light |
NA |
| General Function |
Heartbeat,mirror,flash log,password reset via email,password protection,anti-banding |
| Package Dimension |
210 mm × 116 mm × 106 mm (8.3" × 4.6" × 4.2") |
| Storage Conditions |
-30 °C to 60 °C (-22 °F to 140 °F). Humidity 95% or less (non-condensing) |
| With Package Weight |
Approx. 465 g (1.0 lb.) |
| Startup and Operating Conditions |
-30 °C to 60 °C (-22 °F to 140 °F). Humidity 95% or less (non-condensing) |
| Network |
|---|
| API |
ONVIF (Profile S, Profile G, Profile T),ISAPI,SDK,ISUP |
| Client |
iVMS-4200,Hik-Connect |
| Security |
Password protection, complicated password, watermark, basic and digest authentication for HTTP, WSSE and digest authentication for Open Network Video Interface, security audit log, host authentication (MAC address) |
| Protocols |
TCP/IP, ICMP, DHCP, DNS, HTTP, RTP, RTSP, RTCP, NTP, IPv4, IPv6, IGMP, UDP, QoS, FTP, SMTP |
| User/Host |
Up to 32 users
3 user levels: administrator, operator, and user |
| Web Browser |
Plug-in required live view: Chrome 80+, Firefox 80+, Edge 89+, Safari 13+,
Plug-in free live view: Chrome 80+, Firefox 80+, Edge 89+ |
| Simultaneous Live View |
Up to 6 channels |
| Approval |
|---|
| EMC |
CE-EMC: EN 55032:2015+A1:2020, EN 50130-4:2011+A1:2014, EN IEC 61000-3-2:2019+A1:2021, EN 61000-3-3:2013+A1:2019+A2:2021 |
| Safety |
CB: IEC 62368-1: 2014+A11,
CE-LVD: EN 62368-1: 2014/A11: 2017 |
| Protection |
IP67: IEC 60529-2013 |
| Environment |
CE-RoHS: 2011/65/EU,
WEEE: 2012/19/EU |
| Interface |
|---|
| Reset Key |
NA |
| Built-in Speaker |
NA |
| On-Board Storage |
NA |
| Ethernet Interface |
1 RJ45 10 M/100 M self-adaptive Ethernet port |
| Built-in Microphone |
Yes,1 built-in microphone |
| Illuminator |
|---|
| IR Wavelength |
850 nm |
| Supplement Light Type |
IR,White Light |
| Smart Supplement Light |
Yes |
| Supplement Light Range |
Up to 30 m |
| Pixel Density |
|---|
| DORI |
2.8 mm, D: 61 m, O: 24 m, R: 12 m, I: 6 m
4 mm, D: 68 m, O: 27 m, R: 13 m, I: 6 m |
