| Lens |
|---|
| Aperture |
F2.2 |
| Iris Type |
Fixed |
| Lens Type |
Fixed focal lens, 2.8 and 4 mm optional |
| Lens Mount |
M12 |
| Focal Length & FOV |
2.8 mm, horizontal FOV 94°, vertical FOV 49°, diagonal FOV 114°
4 mm, horizontal FOV 70°, vertical FOV 35°, diagonal FOV 85° |
| Audio |
|---|
| Audio Type |
Mono sound |
| Audio Bit Rate |
64 Kbps (G.711ulaw)/16 to 64 Kbps (AAC-LC) |
| Audio Compression |
G.711/AAC-LC |
| Audio Sampling Rate |
8 kHz/16 kHz |
| Environment Noise Filtering |
Yes |
| Event |
|---|
| Linkage |
Upload to memory card, notify surveillance center, send email, trigger recording, trigger capture, audible warning, flashing light |
| Basic Event |
Motion detection (support alarm triggering by specified target types (human and vehicle)),video tampering alarm,exception |
| Image |
|---|
| SNR |
≥ 52 dB |
| Privacy Mask |
4 programmable polygon privacy masks |
| Image Settings |
Saturation,brightness,contrast,sharpness,gain,white balance,adjustable by client software or web browser |
| Day/Night Switch |
Day,Night,Auto,Schedule |
| Image Enhancement |
BLC,HLC,3D DNR |
| Wide Dynamic Range (WDR) |
Digital WDR |
| Video |
|---|
| H.264 Type |
Baseline Profile,Main Profile,High Profile |
| H.265 Type |
Main Profile |
| Sub-Stream |
50 Hz: 20 fps (768 x 432)
60 Hz: 20 fps (768 x 432) |
| Main Stream |
50 Hz:
20 fps (2560 × 1440, 1920 × 1080, 1280 × 720)
60 Hz:
20 fps (2560 × 1440, 1920 × 1080, 1280 × 720) |
| Video Bit Rate |
32 Kbps to 8 Mbps |
| Bit Rate Control |
CBR,VBR |
| Video Compression |
Main stream: H.265/H.264,
Sub-stream: H.265/H.264/MJPEG |
| Region of Interest (ROI) |
1 fixed region for main stream |
| Scalable Video Coding (SVC) |
H.264 and H.265 encoding |
| Camera |
|---|
| Day & Night |
IR cut filter |
| Image Sensor |
1/2.7" Progressive Scan CMOS |
| Shutter Time |
1/3 s to 1/100,000 s |
| Max. Resolution |
2560 × 1440 |
| Angle Adjustment |
Pan: 0° to 360°,tilt: 0° to 90°,rotate: 0° to 360° |
| Min. Illumination |
Color: 0.01 Lux @ (F2.2, AGC ON),B/W: 0 Lux with IR |
| General |
|---|
| Power |
12 VDC ± 25%, 0.75 A, max. 9 W,Ø5.5 mm coaxial power plug,reverse polarity protection |
| Weight |
Approx. 380 g (0.84 lb.) |
| Language |
English, Ukrainian |
| Material |
Plastic |
| Dimension |
238.5 mm × 97.6 mm × 67.4 mm (9.39" × 3.84" × 2.65") |
| Flashing Light |
Yes,White Light |
| General Function |
Heartbeat,anti-banding,mirror,password protection,password reset via email |
| Package Dimension |
530 mm × 524 mm × 325 mm (8.5" × 4.8" × 4.6") |
| Storage Conditions |
-30 °C to 40 °C (-22 °F to 104 °F). Humidity 95% or less (non-condensing) |
| With Package Weight |
Approx. 722 g (1.59 lb.) |
| Startup and Operating Conditions |
-30 °C to 40 °C (-22 °F to 104 °F). Humidity 95% or less (non-condensing) |
| Network |
|---|
| API |
Open Network Video Interface (Profile S, Profile T, Profile G),ISAPI,SDK,ISUP |
| Client |
iVMS-4200,Hik-Connect |
| Security |
Password protection, complicated password, HTTPS encryption, watermark, basic and digest authentication for HTTP/HTTPS, WSSE and digest authentication for Open Network Video Interface, RTP/RTSP over HTTPS, security audit log, TLS 1.2, TLS 1.3, host authentication (MAC address) |
| Protocols |
TCP/IP, ICMP, DHCP, DNS, DDNS, HTTP, RTP, RTCP, RTSP, NTP, IGMP, IPv4, IPv6, UDP, QoS, SMTP, SNMP |
| User/Host |
Up to 32 users
3 user levels: administrator, operator, and user |
| Web Browser |
Local service: IE11, Chrome 57.0+, Firefox 52.0+, Edge 89+ |
| Simultaneous Live View |
Up to 6 channels |
| Approval |
|---|
| EMC |
CE-EMC: EN 55032:2015+A1:2020, EN 50130-4:2011+A1:2014, EN IEC 61000-3-2:2019+A1:2021, EN 61000-3-3:2013+A1:2019+A2:2021,
IC: ICES-003: Issue 7,
KC: KN32: 2015, KN35: 2015 |
| Safety |
CB: IEC 62368-1: 2014+A11,
CE-LVD: EN 62368-1: 2014/A11: 2017,
BIS: IS 13252 (Part 1): 2010/IEC 60950-1: 2005 |
| Protection |
IP67: IEC 60529-2013 |
| Environment |
CE-RoHS: 2011/65/EU,
WEEE: 2012/19/EU,
Reach: Regulation (EC) No 1907/2006 |
| Interface |
|---|
| Reset Key |
Yes |
| Built-in Speaker |
Max. power consumption: 1.5 W, max. sound pressure level: 10 cm: 95 dB. |
| On-Board Storage |
Built-in memory card slot, support microSD/microSDHC/microSDXC card, up to 512 GB |
| Ethernet Interface |
1 RJ45 10 M/100 M self-adaptive Ethernet port |
| Built-in Microphone |
Yes,1 built-in microphone |
| Illuminator |
|---|
| IR Wavelength |
850 nm |
| Supplement Light Type |
IR,White Light |
| Smart Supplement Light |
Yes |
| Supplement Light Range |
Up to 30 m |
| Pixel Density |
|---|
| DORI |
2.8 mm, D: 68 m, O: 27 m, R: 13 m, I: 6 m
4 mm, D: 100 m, O: 39 m, R: 20 m, I: 10 m |
| Mobile Communication |
|---|
| Standard |
LTE-FDD |
| Frequency |
LTE-FDD: B1/3/5/7/8/20/28 |
| SIM Card Type |
Nano SIM |
| Uplink and Downlink Data Rate |
Cat 1, uplink: 5.1 Mbps, downlink: 10.3 Mbps |
