| DORI |
|---|
| DORI |
2.8 mm, D: 59 m, O: 23 m, R: 11 m, I: 5 m
4 mm, D: 79 m, O: 31 m, R: 15 m, I: 7 m |
| Lens |
|---|
| Aperture |
F2.0 |
| Iris Type |
Fixed |
| Lens Type |
Fixed focal lens, 2.8 and 4 mm optional |
| Lens Mount |
M12 |
| Focal Length & FOV |
2.8 mm, horizontal FOV 99°, vertical FOV 55°, diagonal FOV 116°
4 mm, horizontal FOV 76°, vertical FOV 41°, diagonal FOV 90° |
| Audio |
|---|
| Audio Type |
-U: Mono sound |
| Audio Bit Rate |
-U: 64 Kbps (G.711 ulaw)/64 Kbps (G.711 alaw)/16 Kbps (G.722.1)/16 Kbps (G.726)/32 to 160 Kbps (MP2L2)/16 to 64 Kbps (AAC-LC) |
| Audio Compression |
-U: G.711ulaw/G.711alaw/G.722.1/G.726/MP2L2/PCM/AAC-LC |
| Audio Sampling Rate |
-U: 8 kHz/16 kHz |
| Environment Noise Filtering |
-U: Yes |
| Event |
|---|
| Linkage |
Upload to FTP/memory card (-F), send email, notify surveillance center, trigger recording (-F), trigger capture |
| Basic Event |
Motion detection (support alarm triggering by specified target types (human and vehicle)), video tampering alarm, exception |
| Image |
|---|
| SNR |
≥ 52 dB |
| Privacy Mask |
4 programmable polygon privacy masks |
| Image Settings |
Rotate mode, saturation, brightness, contrast, sharpness, gain, white balance, adjustable by client software or web browser |
| Day/Night Switch |
Day, Night, Auto, Schedule |
| Image Enhancement |
BLC, HLC, 3D DNR |
| Wide Dynamic Range (WDR) |
120 dB |
| Video |
|---|
| H.264 Type |
Baseline Profile/Main Profile/High Profile |
| H.265 Type |
Main Profile |
| Sub-Stream |
50 Hz: 25 fps (1280 × 720, 640 × 480, 640 × 360)
60 Hz: 24 fps (1280 × 720, 640 × 480, 640 × 360) |
| Main Stream |
50 Hz:
20 fps (2560 × 1440)
25 fps (1920 × 1080, 1280 × 720)
60 Hz:
20 fps (2560 × 1440)
24 fps (1920 × 1080, 1280 × 720) |
| Video Bit Rate |
32 Kbps to 8 Mbps |
| Bit Rate Control |
CBR/VBR |
| Video Compression |
Main stream: H.265+/H.265/H.264+/H.264
Sub-stream: H.265/H.264/MJPEG |
| Region of Interest (ROI) |
1 fixed region for main stream |
| Camera |
|---|
| Day & Night |
IR cut filter |
| Image Sensor |
1/3" Progressive Scan CMOS |
| Shutter Time |
1/3 s to 1/100,000 s |
| Max. Resolution |
2560 × 1440 |
| Angle Adjustment |
Pan: 0° to 360°, tilt: 0° to 90°, rotate: 0° to 360° |
| Min. Illumination |
Color: 0.01 Lux @ (F2.0, AGC ON), B/W: 0 Lux with IR |
| General |
|---|
| Power |
12 VDC ± 25%, 0.4 A, max. 5 W, Ø5.5 mm coaxial power plug
PoE: 802.3af, Class 3, 36 V to 57 V, 0.2 A to 0.15 A, max. 6.5 W |
| Weight |
Approx. 270 g (0.6 lb.) |
| Language |
English, Ukrainian |
| Material |
Metal & Plastic |
| Dimension |
170.8 mm × 66 mm × 69.1 mm (6.7" × 2.6" × 2.7") |
| General Function |
Heartbeat, anti-banding, mirror, password protection, password reset via email |
| Package Dimension |
216 mm × 121 mm × 118 mm (8.5" × 4.8" × 4.6") |
| Storage Conditions |
-30 °C to 60 °C (-22 °F to 140 °F). Humidity 95% or less (non-condensing) |
| With Package Weight |
Approx. 481 g (1.1 lb.) |
| Startup and Operating Conditions |
-30 °C to 60 °C (-22 °F to 140 °F). Humidity 95% or less (non-condensing) |
| Network |
|---|
| API |
Open Network Video Interface (Profile S, Profile T, Profile G (only -F model supports)), ISAPI, SDK |
| Client |
iVMS-4200, Hik-Connect |
| Security |
Password protection, complicated password, watermark, basic and digest authentication for HTTP, WSSE and digest authentication for Open Network Video Interface, security audit log, host authentication (MAC address) |
| Protocols |
TCP/IP, ICMP, DHCP, DNS, HTTP, RTP, RTSP, NTP, IGMP, IPv6, UDP, QoS, FTP, SMTP |
| User/Host |
Up to 32 users
3 levels: administrator, operator, and user |
| Web Browser |
Plug-in required live view: IE 10, IE 11
Local service: Chrome 57.0+, Firefox 52.0+ |
| Simultaneous Live View |
Up to 6 channels |
| Approval |
|---|
| EMC |
FCC: 47 CFR Part 15, Subpart B
CE-EMC: EN 55032: 2015, EN 61000-3-2:2019, EN 61000-3-3: 2013+A1:2019, EN 50130-4: 2011 +A1: 2014
RCM: AS/NZS CISPR 32: 2015
IC: ICES-003: Issue 7
KC: KN32: 2015, KN35: 2015 |
| Safety |
UL: UL 62368-1
CB: IEC 62368-1: 2014+A11
CE-LVD: EN 62368-1: 2014/A11: 2017
BIS: IS 13252 (Part 1): 2010/IEC 60950-1: 2005 |
| Protection |
IP67: IEC 60529-2013 |
| Environment |
CE-RoHS: 2011/65/EU
WEEE: 2012/19/EU
Reach: Regulation (EC) No 1907/2006 |
| Interface |
|---|
| Reset Key |
-F: Yes |
| On-Board Storage |
-F: Built-in memory card slot, support microSD/microSDHC/microSDXC card, up to 256 GB |
| Ethernet Interface |
1 RJ45 10 M/100 M self-adaptive Ethernet port |
| Built-in Microphone |
-U: Yes |
| Illuminator |
|---|
| IR Wavelength |
850 nm |
| Supplement Light Type |
IR |
| Smart Supplement Light |
Yes |
| Supplement Light Range |
Up to 30 m |
