| General |
|---|
| Net Weight |
0.26 kg (0.57 lb) per device |
| Gross Weight |
1.1 kg (2.43 lb) |
| Packing List |
Wireless Bridge × 2,Binding Tape × 4,Quick Start Guide ×1,Regulatory Compliance and Safety Information × 1,PoE Power Supply × 2,AC Cord × 2 |
| Packing Method |
Packing in pairs |
| Storage Humidity |
5% to 95% (no condensation) |
| Working Humidity |
5% to 95% (no condensation) |
| Installation Mode |
Pole Mounting |
| Power Consumption |
1.8 W for typical (1-ch 2MP IPC), Max. 4.5 W |
| Ingress Protection |
IP55 |
| Storage Temperature |
-40 °C to 80 °C (-40 °F to 176 °F) |
| Working Temperature |
-30 °C to 60 °C (-22 °F to 140 °F) |
| Package Dimensions (W × H × D) |
256 mm × 231 mm × 86 mm (10.07" × 9.09" × 3.38") |
| Product Dimensions (W × H × D) |
90.8 mm × 187.87 mm × 57.87 mm (3.57'' × 7.39'' × 2.27'') |
| Approval |
|---|
| EMC |
CE-EMC(EN 55032, EN 50130-4, EN 55035, EN IEC 61000-3-2, EN 61000-3-3) |
| Radio |
EN 301 489-17,EN EN 301 489-1,EN 61000-3-3, EN IEC 61000-3-2, EN 300 328, EN IEC 62311 |
| Safety |
CB (IEC 62368-1),CE-LVD (EN 62368-1) |
| Chemistry |
CE-RoHS (2011/65/EU),WEEE (2012/19/EU),Reach (Regulation (EC) No.1907/2006) |
| PoE Power Supply |
|---|
| PoE Port |
AP: LAN1 802.3af/at PoE IN; CPE: LAN1 passive PoE IN, LAN2 802.3 af PoE OUT |
| PoE Distance |
100 m |
| PoE Power Budget |
10 W |
| Software Function |
|---|
| HPP |
Support one-click activation and remote management via Hik-Partner Pro. Functions supported:
1. Reboot device
2. Restore device
3. Display the topology information
4. Display the connection status between AP and CPEs, including signal intensity, background noise, sending & receiving rate
5. Configure wireless settings, including working mode, SSID, password, channel, channel bandwidth, transmitting power
6. Bridge alignment
7. Spectrum scanning
8. PoE output management |
| Upgrade |
Web,iVMS-4200,HCP,HPP |
| System Log |
Syslog,Control center information |
| Channel Width |
10/20/40 MHz |
| Security Mode |
WPA2-PSK |
| Network Protocol |
NTP (network time synchronization),SADP (auto search for IP address), HTTPS/HTTP (web management),SSH (debugging) |
| Channel Selection |
Auto/manual selection |
| Management Method |
HCP,Web,iVMS-4200,HPP |
| Security Mechanism |
Wireless network name hidden |
| Application Function |
IFM,IPM |
| Hardware Parameter |
|---|
| Reset |
Hardware resetting button |
| Power Supply |
48V PoE;Check the physical interface image below for more details |
| LED Indicator |
Power indicator,LAN indicator,Signal intensity indicator |
| Network Interface |
2 × 10/100 Mbps RJ45 ports |
| Wireless Parameter |
|---|
| Antenna Gain |
7 dBi |
| Antenna Angle |
(H) Beamwidth [3 dB] 60°, (V) Beamwidth [3 dB] 50° |
| Throughput Rate |
PTP: 90 Mbps/0.2 KM(HT40),90 Mbps/0.5 KM(HT40),70 Mbps/1 KM(HT40),PTMP(1 to 4): 40 Mbps/1 KM(HT40) |
| Wireless Standard |
IEEE 802.11b/g/n (2 × 2 MIMO 300 Mbps) |
| Transmitting Power |
22 dBm @11n MCS0 (Note: Transmitting power may vary with local regulations.) |
| Receiving Sensitivity |
-87±2 dBm @HT40 MCS0 |
| Working Frequency Band |
2400 MHz ~ 2483.5 MHz |
| Max. Transmission Rate of Air Interface |
≤ 300 Mbps |
